SPECIFICATIONS AND INVENTORY:
HULL: (constructed by Longitude Cero Composites in Spain)
• The hull was constructed from a female mold. Its inner and outer skins are a carbon laminate with honeycomb and foam core. All laminates are bonded using a carbon epoxy pre-preg which was heat cured under vacuum. The bulkheads, keel floors, and longitudinal are constructed of carbon fiber. The laminates are bonded with epoxy resin using an infusion process and then heat cured under vacuum.
DECK: (constructed by Longitude Cero Composites in Spain)
• The deck was constructed using a female mold. Its construction is of carbon laminates and honeycomb core, which are bonded using a carbon epoxy prepreg, followed by heat curing under vacuum. High density core was used in high load areas where winches and deck fittings are located.
INTERIOR CONSTRUCTION:
• The interior components are constructed using carbon laminates and foam.
KEELS:
• There are two keel fins and keel bulbs. A 2015 IRC Keel 3.65m Draft with 3.9t Bulb (In Newport, RI). 2024 ORC Keel Fin with Trim Tab and Bulb, 3.8m Draft with 3.95t Bulb.
• Vesper is set up to race, IRC, ORC, ORR and CSA.
• The ORC/CSA keel fin is a milled steel fin with a draft of 3.8m
• The IRC and ORR keel fin is composite carbon and steel with a draft of 3.65 meters.
• All the keel fins and bulbs are faired to Americas Cup standards and finished to perfection.
RUDDERS:
• The rudder has a carbon prepreg rudder stock with JP3 self aligning rudder bearings.
• The rudder blade is constructed of foam and carbon laminates.
• Spare rudder
STEERING:
• Composite Tiller
• Spare Tiller and extension with securing point in hull while racing
• Carbon Fiber Spinlock Hiking Extension
PAINTWORK:
• Exterior: The hull above and below the waterline is faired and painted while the boatis hanging using Allgrip HD primers and clear coats. The hull and bottom are wet sanded and buffed to a mirror finish.
The deck smooth areas and cockpit walls are painted with Awlcraft 2000. The deck is painted with Awlgrip using Alwgrips nonskid.
• The cockpit has applied rubberized nonskid.
ENGINE:
• 2015 Lombardini light weight racing engine with SD60 sail drive (ORC optimized)
• Lombardini LDW1404 engine
• 2 Blade Gori Racing propeller
ELECTRICS:
• Navigation lights
• 2, batteries for electronics and engine starting
• Engine Spinnlock Gear Shift on cockpit wall
• Engine control panel on engine box below deck
CUSTOM HARDWARE:
• Fiberglass Bow pulpits
• Fiberglass stern pulpits
• E glass stanchions with double lifelines. Stanchions are fitted into glass tubes in deck
• Composite chainplates
• Forestay and backstay fittings
• Laminated carbon fiber mast collar
DECK HARDWARE:
• Includes Harken winch system, halyard jammer system, portlights, tracks, cars, blocks, padeyes, hydraulics & plumbing, mast base, chainplate pins, main hatch, forward hatch
HYDRAULICS – By Harken:
• Headstay ram
• Spare Headstay Ram
• Deflector ram mounted on mast
• Mast butt ram
• Harken Rotary Pump
• Hydraulics driven on aft pedestal.
• Hydraulic controls on stb cockpit wall
WINCHES – By Harken:
• One pit winch
• Two primary winches
• Two mainsheet winches
• Two runner winches
• Forward pedestal & aft pedestals
SPARS AND RIGGING – by Hall Spars:
• High modulus carbon fiber triple spreader mast 2014
• Carbon fiber box boom 2014
• 2019 EC6 Rigging upgrade. Serviced at Future Fibers Spain in 2022
• EC6 backstays (twin top mast runners)
• Deflector system
• Adjustable rake while sailing
• Adjustable mast butt while sailing
• 2020 Added 2nd Checkstay
• 2020 Added Masthead Halyard Lock and Genoa Staysail Sheave
• Fractional Halyard Lock
ELECTRONICS:
• Complete B&G WTP2 sailing package
• Instrument bracket with 4 x 20/20, 2 x GFD
• Cockpit instruments – 3 x FFD, 1 x GFD, 4 x 10/10
• Compass B&G IMU and Halcyon 2000
• ICOM M412 VHF radio
• AIS
• Panasonic CF-74 Toughbook PC x 2
• G-Tac Tablet
• Deckman and Expedition Navigation software
• Heel Sensor
• Linksys Router AC1900 x 2
• String pot Sensors x 3
• Hydro Load Sensor x 2
• Forestay load pin
• 2021 V1 Load Pins added
• 2021 Checkstay Cyclops Load Cell
Miscellaneous:
13 Spinlock Lifejackets w Tethers
Anchor and Rope/chain
1 Spare Tiller extension
1 Spare Hall Spar - 2014 on top of shed at KKMI 2 SCR Shrouds - 2014 in tube taped to mast
2 Gorilla headfoil
Spare boom
2 Masthead wands
2 Race Running backstays
2 Spare/old backstays
1 new forestay pennant
4 Used forestay pennants
2 Rod D1's w/ Turnbuckles
1 Mast Jack
4 Tacklines
4 2:1 tackline
2 Handy billy for Fr0
1 Frac Haly
10 Runner tails
6 Spin halyards
3 Jib Halyards
3 Main halyards
4 Spin sheets
5 Jib Sheets
2 Staysail sheets
1 Inshore Prod
1 Offshore Prod with bobstay
1 Emergency bobstay
1 Race rudder on the yacht
1 Spare rudder
1 Race tiller
1 Spare tiller
7 Docklines
4 Deck brushes/chamois
2 Rubber shackles for docklines
5 gal fuel jerry and funnel Misc.
Life line hiking pads
2 Mast Carts
2 Shroud chafe guards 2 Keel Fin chocks
Container 40 ft HC Container # VSPR 501978-4 (Insulated, fitted for US and European Power)
Many Miscellaneous spares (full inventory available to serious inquiries.
