Accommodations
Berths for six in three double cabins with 3 heads + 2 (converted bed in the saloon)
FORWARD’S OWNER CABIN:
Full width of the hull, very light, and well ventilated, 3 deck hatches and 2 hull port lights, LED lighting, Reading lamps
Central 1.60m double bed. Large storage spaces under the bed with drawers and top access. Desk unit/dressing table to starboard, air conditioning and heating. Water-heater (40 litres) dedicated to the forward cabin bathroom.The ensuite head: separate cabin shower
Lighting by deck hatch, spot lamps
Lockers, towel rail, clothes hooks
Electric marine toilet with black water tank
A/C outflow.
PORT AFT GUEST CABIN
Access to the cabin is via the passageway
Ventilation and daylight by fixed port lights, and opening hatch and port lights. General lighting by spot lamps, reading lamps, indirect lighting and night marker lights, the majority by LEDs. Central double bed with bedside units
Numerous storage spaces in closed and open lockers. 220V socket, air-conditioning, and heating.
Ensuite head: separate cabin shower
Lighting by deck hatch, spot lamps
Lockers, towel rail, clothes hooks
Electric marine toilet with black water tank
A/C outflow.
STARBOARD AFT CABIN
Access to the cabin is via the passageway
Twin single beds. 220 V sockets, air conditioning & heating
Access to the stern thruster.
ensuite head STBD aft cabin:
Separated cabin shower
Lighting by deck hatch, spot lamps
Lockers, towel rail, clothes hooks
Electric marine toilet with black water tank, 220V socket, air-conditioning, and heating. Behind the shower door,
area for laundry : MIELE washing machine/dryer.
SALOON: Built-in refrigerator/freezer is installed under saloon seat, running with sea water or air, under the dining area settee. The salon is very light and spacious. It provides an excellent view of the outside from its 4 opening hatches, its opening port hole and 4 large port lights. The companionway is well protected by the wheelhouse and can even remain open in rainy weather. Air-conditioning and heating. Numerous electrical sockets
The saloon is designed with a vast combined dining and lounge area, including an adjustable table (sliding, swivelling, folding and with telescopic foot) with a very big U-shaped seat around, which can be converted for a double bed.
Navigation Systems
At the helm station :
B&G wind indication, 2 X Hydra 3000 B&G Central including speedo, log, depth Sounder, wind sensor.
MFD 12’’ Furuno with RADAR XN12 Furuno. The electronic charts were updated and include all med.
Control buttons at helm station for sails. 2 Lewmar chain control. Bow and stern thruster control Max Power.
VHF Garmin GHS 11i radio with DSC and repeater at chart table (2024)
Autopilot : Two independent system
1 x FURUNO NAVPILOT autopilot + hydraulic cylinder LS from 2022 + Computer
1 x FURUNO NAVPILOT autopilot + Second Cylinder LS + second computer
1 x magnetic compass Plastimo (compass card 2024)
At chart table :
GARMIN GHS11i VHF radio with DSC and repeater at helm station 2024
Central Hydra 3000 B&G including wind, speedo, log and depth, Sounder
FURUNO GPS 33 receiver
MFD 12" Furuno plotter with Radar and can be view on saloon TV.
Mastervolt Batteries monitor digit display
Marine AIS em-track 200 class "A"
Equipment
Very spacious watertight engine room, with very efficient sound insulation. The engine and all the heavy equipment (generator set and batteries) are centred and positioned very low High density insulating foam
Automatic fire extinguishing system.
Access: from the cockpit, and via a watertight door below in the passageway
Steyr 6-cylinder, 150 HP, four stroke, six cylinders, turbocharged diesel engine and chain distribution.
110 kW @ 2,500 rpm. Hydraulic gearbox with shaft brake
AMEL C-Drive, five diesel fuel filters with a 3-way tap and replaced all years. Filter for engine, genset, heating.
Propeller Type:3 blade, folding.
GENERATOR: Onan 4-cylinder 19 KVA, 230V/50Hz
2200 Running hours, motor refit 2025.
WATERMAKER: DESSALATOR watermaker 24 /220 V. 150 L /H capacity.
AIR CONDITIONNING AND HEATING: CLIMMA reversible air conditioning unit with two compressors. Sea water pump, 19 000 BTU & 16 000 BTU
Webasto diesel heating system 24V, air heating system.
BATTERIES: Mastervolt GEL, 8 X 183 A 24V (2022)
1 X 12V/90Ah main engine starting battery (2022)
1 X 12V/85Ah generator starting battery (2022)
2 X 12 V / 200 Ah Mastervolt gel banks (2022) for bow/stern thruster, genoa and staysail furlers and windlasses batteries. Dedicated charger 60 A MASTERVOLT Additional charger 24/24 MAGIC for charging.
Starting banks are charged by the main engine and generator driven alternators and by one MASTERVOLT 12V battery charger.
BOW AND STERN THRUSTERS: MAX POWER retractable 20 hp electric bow and stern thrusters. 2 batteries 200A (2022) dedicated for the Bow thruster.
Stern thrusters are connected to service batteries
Genset runs to use it.
Galley Equipment
Situated to the right of the companionway at a slightly lower level, it is very large and is a major feature of the life on board, lighting and ventilation are excellent
Large Corian working surface combination of low units, drawers and high storage. MIELE gimbal-mounted 4-burner Miele stove DE DIETRICH Electric extractor hood with filter. MIELE Electric oven, 220V
MIELE Stainless steel microwave oven/grill, 220V
Stainless steel short cycle dishwasher MIELE
FRIGOBOAT stainless steel refrigeration unit with one 180 L refrigerator and one 130 L front-opening freezer. Two compressors for fridge & freezer work with sea water.
Several 220V sockets. Sink with fresh water and a seagull filter.
Deck and Hull Equipment
SAILS: INCIDENCE Spectra genoa 90 m2 – triradial cut –
INCIDENCE Spectra staysail 30 m2 – triradial cut
INCIDENCE Spectra mainsail 58 m2 – triradial cut with
INCIDENCE Spectra mizzen 30 m2 – triradial cut with electrical windlass and button at bottom mast
INCIDENCE Gennaker 120 m2. Original Sails, serviced recently.
WINCHES: Two (2) LEWMAR 50 ST halyard winches on the main mast
Two (2) LEWMAR 68 ST genoa sheet 2-speed electric winches.
Two (2) LEWMAR 58 ST staysail sheet 2-speed electric winches.
One (1) LEWMAR 50 ST main sheet 2-speed electric winch.
One (1) LEWMAR 48 ST mizzen sheet 2-speed electric winch.
One (1) LEWMAR 40 ST 2-speed electric winch for the tender launching.
