Optional Equipment Fitted
DIMENSIONS:
L.O.A: 59’ 5” (18.11m)
Beam: 15’ 7” (4.76m)
Draft: 4’ 3” (1.29m)
Displacement: 59,084 lbs (26,800Kg)
Fuel Capacity: 582 galls (2,650 ltrs)
Water capacity: 130 galls (592 ltrs)
ENGINES & DRIVE:
Twin CATERPILLAR C12A-715 (2 x 715mhp) Diesel Engines
Running hours: 1,900 (December 2024)
Sternthruster (130 KgF)
HULL COLOUR:
White (with dark blue water line & dark blue antifouling, hull & bathing platform fendering is white with stainless steel insert)
INTERIOR FURNITURE:
Walnut interior wood Satin finish (Walnut galley floor as standard)
LAYOUT:
Aft Cabin fit out (single berth with electric toilet and washbasin, hand held shower with electric pump out, overhead berth lighting and opening porthole including mosquito screens). Extractor fan in toilet compartment, transom window in safety glass with venetian blind.
Starboard cabin to have powered double berth conversion (inboard berth slides outboard)
GALLEY:
Galley avonite to be advised
Cocoa Brown galley worktop
DECK HARDWARE:
Electro-hydraulic swimming platform (400Kg SWL)
Additional 20m of 10mm anchor chain to give a total of 60 metres
Freshwater Maker
GENERATOR:
ONAN 13.5 kW/ 50 Hz generator in place of standard
Running hours: 6,420 (December 2024)
ELECTRICAL:
Foredeck freshwater anchor / deckwash system
Icemaker (fitted in saloon)
NAVIGATION:
Raymarine e125 Chartplotter/GPS with external GPS and 12.1" brilliant colour multifunction display at lower helm
Raymarine SHD digital colour radar with 48", 4Kw scanner (only if chartplotter is specified)
Raymarine e125 multifunction 12.1" brilliant colour display at upper helm
Raymarine AIS Class B transponder interfaced with chartplotter & with 8ft (2.4m) aerial
AIRCONDITIONING:
Reverse Cycle Airconditioning/Heating : (64,000 BTU) Suitable for ambient temperature to 35°C (e.g. Florida/Eastern Mediterranean) with controls in all cabins and outlets in all areas (including bathroom)Recommended generator : 13.5 kW
Aft cabin airconditioning (trunked from Saloon)
HOLDING TANK / TOILETS:
Aft cabin toilet to be connected into holding tank system
System 2 : Toilet discharging into the holding tank but also having the ability to discharge directly overboard via a Y valve fitted in the discharge lines. The holding tank has electric overboard discharge as well as reserve manual pump out and dockside discharge arrangements.
EXTERIOR UPHOLSTERY / CANVAS / COVERS:
Cockpit seating & aft sunbed cushions in Movida Metallic
Colour : BEIGE Inlay : MOCCA
