Equipment list
Type of the engine:
- Turbo diesel
- Model of the engine: aquamatic inboard-outboard
- Kad 300 edc/dp-g
- Manufacturer: volvo penta
- Number of installed engines: 2
- Total displacement cm³: 3590 cm³
- Number of cylinders: 6 cylinders, in-line
- Maximum power kw (hp), certified in italy: 210 kw (285 hp)
- Financial classification: 30
- Maximum revolutions/min: ** 3700/3800
- Fuel supply: direct injection
- Weight: 542 kg
Technical data:
- Total length of the hull: 11.75 m
- Length of the hull: 10.92 m
- Waterline length: 9.93 m
- Width of the hull: 3.80 m
- Maximum width: 3.84 m
- Height of the submerged part in water: 3.12 m
- Transport height (including radar arch): 3.40 m
- Draft at the keel: 0.79 m
- Draft at the propellers: 0.97 m
- Design category: b
- Usable engines: diesel, inside deck- deck
- Maximum performance – diesel: 420 kw (570 hp)
- Boat weight with engine: 6400/6500 kg
- Maximum displacement with full load: 8310 kg
- Fuel tank capacity: 640 l
- Water tank capacity: 270 l
- Boiler capacity: 18 l
- Max. Number of persons to be carried: 10 persons
- Maximum load (including persons): 950 kg
- Number of beds: 4
- Engine and service batteries: 2 × 120 ah (2025)
- Battery voltage: 12 v direct current
- Shore connection voltage: 230 v ac – 50 hz / 115 v ac – 60 hz (usa)
Ship's extra and basic equipment:
- electric anchor – 30 m chain – 2 extra 16 kg anchors
- teak wood covering around the anchor, replaced 8 years ago (2017
- teak wood covering on the bathing platform – replaced 8 years ago (2017)
- carpet covering on deck – replaced 3 years ago (2022)
- deck table can be converted into a reclining area
- full leather covering on deck – replaced 2 years ago (2023)
- blue summer tarpaulin, complete with a rear sunbathing area, with a white light filter at the end.
- four-person inflatable boat with electric yamaha engine, separate working battery
- electric gangway from the aft bridge, with teak wood covering and remote control.
- bathing ladder.
- 2 refrigerators on deck, one on deck, the other in the cabin
The boat has + 1 raymarine gps plotter system.
- bow thruster
- navigation lights
- vhf radio and speaker
- mosquito nets on the boat windows
- two-plate electric stove, microwave oven
- 2 televisions
- glomex automatic antenna
- deck shower
- electric toilet, washbasin and shower
- 3 washbasins, 1 sink
- 18 liter hot water boiler
- shore power connection
- 4 kw generator - with separate battery
- automatic battery charger
- 2 120 ah batteries (2025)
- air conditioning, refrigerator - heater - 8000 btu
- 2 "z" drive engines - starboard 2020, port 2022 were replaced.
- the boat has an engine and transmission inspection every year. It undergoes a complete oil and filter change every year.
- the fresh water system is cleaned and disinfected every year.
- the electric toilet is flushed and disinfected every year.
- the boat is washed and polished with shampoo every spring.
- the zinc anodes are replaced together with the algae inhibitor.
- the boat's next technical inspection: 2028.09.
The captain’s instrument indicators:
- Switch of the winch – raising/lowering
- Switch of the alarm signal (ship’s horn)
- Switch of the bilge pump
- Switch of the wheelhouse lighting
- Switch of the navigation lights of the ship
- Switch of the lights used during anchoring
- Switch of the windshield wiper
- Autopilot / gps-plotter
- Accessories
- Left stabilizer
- Right stabilizer
- Switch of the bow thruster power supply
- Switch controlling the bow thruster
- Magnetic compass
- Trim indicator
- Revolution counter with timer
- Depth gauge – knotmeter/milemeter
- Water tank level indicator
- Fuel tank level indicator
- Voltage meters
- Oil pressure indicators
- Engine cooling water temperature indicator
- Maps
- Storage space
- Switch panel
- Engine control panel
- Gps/plotter (\*)
- Autopilot
- Trim control
- Steering angle
- Edc control
- Gearshift/throttles
- Wheel
- Side control desk of the instrument panel
- Checking door behind the instrument panel
- Radio control panel
- Engine indicators panel
- Alarm signal push button
